| BRAND | Berthold |
| Product | 50036-120 |
| Internal code | FBR513415 |
| Weight | 1 |
| Technical specification | Uni-Probe LB 490-91 Level Gauge signal output: FieldbusFoundation scintillator: NaI 50/50 collimator with frontal irradiation power supply 95-250VAC automatic drift compensation automatic decay compensation internal self monitoring ambient temp: -40°C to +50°C - 1 analog output: 0/4 - 20 mA, isolated signal output switchable between FF-Bus and HART - 1 digital-Input for hold-signal - 3 relays, alternative signals: hold, max / min alarm, detector temp., rad. interference - 1 failure relay relays: Max. 250VAC or 30VDC at max. 5A non-inductive 4 conduits radial, 3/4" NPT flame proof protection ATEX: II 2 GD EEx d IIC T6 IP66 T 70°C flame proof protection FM/CSA: Class I, Division 1&2, Groups A, B, C, D Class II, Division 1&2, Groups E, F, G protection: Nema 4X / IP 66 housing: stainless steel Customs tariff number: 90222900 |
