Prices 70640253CY00001 Lowara France

BRAND	Lowara
Product	70640253CY00001
Internal code	FBR3356038
Weight	93
Technical specification	Pumptype: LSN 125-100-200 S1VV1 7502 Identical to s/n 60699101 Single stage endsuction pump according to ISO 5199/5199 with enclosed radial impeller. Process design with heavy duty bearing frame for continuous operation with reinforced shaft and bearings. Thrust bearing at drive side, pair of angular contact bearings, roller bearing at pump side. Materials: Impeller : alloy cast steel, 1.4408 Casing : alloy cast steel, 1.4408 casing cover : alloy cast steel, 1.4408 Shaft : alloy steel, 1.4021 shaft sleeve : Stainless Steel Wear rings : without (Standard) Shaft seal: S1..1 Cyclone seal chamber with smooth shaft sleeve Shaft seal MG912 Single seal rubber bellow, unbalanced Materialcombination : BQ1EGG Fluid : Water, pure Temperature : 20 °C Density : 998,191 kg/m³ Viscosity : 1,000 mm²/s Capacity : 256,0 m³/h Head : 70,0 m Power : 60,6 kW Efficiency : 80,8 % NPSH : 6,26 m Speed : 3550 1/min Req. Motor power : 71,6 kW Suction flange : DN 125, PN16, EN 1092 (IC) horizontal at centerline Discharge flange : DN 100, PN16, EN 1092 (IC) vertical at top-centerline max. Casing pressure : 1600 kPa Suction-/Systempressure : 9,79 kPa Lubrication :Oil (Standard) Oilsump cooling :without Oilsump cooling Constant level oiler :without constant level oiler, with sight glass Labyrinth seals :without Motor Brand : WEG Type : W22 - 280 S/M - 75kW Nom. power : 75 kW Nom. current : 113,0 A Voltage : 460 V Frequency : 60 Hz Speed : 3570 1/min Design : IM B3 Size : 280 S/M Isolation class : F Protection class : IP55

You can find the current prices belongs to Lowara - 70640253CY00001 coded product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. All of the listed products are with guaranteed origin and high quality. It produced result of tests of laborotory for years. 70640253CY00001 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy 70640253CY00001 by Lowara in France?

You can purchase 70640253CY00001 by Lowara from FABRIMAT SARL. We serve customers across France, offering competitive prices and reliable service.

What is the price of the 70640253CY00001 ?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Lowara in France?

While we are not the official distributor or seller of Lowara in France, we source our products from reliable channels and offer you original Lowara equipment at competitive prices.

How can I access 70640253CY00001 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 70640253CY00001 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 70640253CY00001 ?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
