Prices  733280145 LMIX2-000-08.0-1-11  Elgo  France

BRAND Elgo
Product 733280145 LMIX2-000-08.0-1-11
Description Incremental Linear Encoder with 8.0M Cable
Internal code FBR163288
Weight 2
Technical specification
  • Model: LMIX2-000-08.0-1-11
  • Manufacturer: Elgo
  • Measuring Principle: Incremental
  • Resolution: 0.025 mm (at 4-edge triggering)
  • Repeat Accuracy: ±1 increment
  • System Accuracy: ±(25 + 20 x L) µm at 20°C, where L is the measuring length in meters
  • Distance Sensor/Tape: Max. 2.0 mm
  • Sensor Housing Material: Zinc die-cast
  • Housing Dimensions: 30 x 12.5 x 25 mm
  • Pole Pitch: 5 mm
  • Maximum Measuring Length: Theoretically unlimited
  • Connections: Open cable ends
  • Sensor Cable: 8.0 meters
  • Power Supply Voltage: 5 VDC
  • Output Signals: A, A', B, B', Z, Z'
  • Output Levels: TTL
  • Output Current per Channel: Max. 20 mA
  • Maximum Output Frequency per Channel: 100 kHz
  • Operating Speed: Up to 5 m/s
  • Operating Temperature: -10°C to +70°C
  • Protection Class: IP67

Elgo - 733280145 LMIX2-000-08.0-1-11 referenced Incremental Linear Encoder with 8.0M Cable product produced by high technology.
733280145 LMIX2-000-08.0-1-11 became irreplaceable of foundations. 733280145 LMIX2-000-08.0-1-11 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. You can find the most competitive prices about endustriel accessories in our company. Make an offer to us for 733280145 LMIX2-000-08.0-1-11 please contact us.

Where can I buy 733280145 LMIX2-000-08.0-1-11 by Elgo in France?

You can purchase 733280145 LMIX2-000-08.0-1-11 by Elgo from FABRIMAT SARL. We serve customers across France, offering competitive prices and reliable service.

What is the price of the 733280145 LMIX2-000-08.0-1-11?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Elgo in France?

While we are not the official distributor or seller of Elgo in France, we source our products from reliable channels and offer you original Elgo equipment at competitive prices.

How can I access 733280145 LMIX2-000-08.0-1-11 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 733280145 LMIX2-000-08.0-1-11 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 733280145 LMIX2-000-08.0-1-11?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
