Prices 994310822000001 Ephy Mess France

BRAND	Ephy Mess
Product	994310822000001
Internal code	FBR4670967
Weight	1.9
Custom code	90259000
Technical specification	Temperature sensor, TSA015127 2Pt100, 3-wire circuit Class B ±0.3°C at 0°C in accordance with DIN EN 60751 Connection head, brass, height=16mm Size: Ø5xEL=100mm, stainless steel, Mounting hole: for M6 screws without plug, Supply line: shielded hose line 1x [6x0.25mm²-Cu-tinned/Sabix/PP foil/Cu-tinned/PP yarn/Sabix, KL=3000mm, length tolerance: +20, Aø: 5.20mm] BK (WH1/WH2/WH3/WH4/WH5/WH6), Measuring range: -40°C... +200°C Ambient temperature: -40°C... +105°C Temperature sensor: -40°C... +250°C Temperature - head: -40°C... +150°C Insulation resistance: ≥ 200 MΩ/500 VDC Insulation resistance element to element: ≥ 200 MΩ/500 VDC IP protection class: IP 66 (only applies to the sensor head) Shield placed on sensor housing 1. PT100: braid: strand number 1, 1. PT100: braid: strand number 2, 1. PT100: braid: strand number 3, 2. PT100: braid: strand number 4, 2. PT100: wire: strand number 5, 2. PT100: braid: strand number 6, PT100 (1): pin 1/2 - pin 3 PT100 (2): pin 4/5 - pin 6

You can find the current prices belongs to Ephy Mess - 994310822000001 coded product. 994310822000001 became irreplaceable of foundations. 994310822000001 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for 994310822000001 Ephy Mess . 994310822000001 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy 994310822000001 by Ephy Mess in France?

You can purchase 994310822000001 by Ephy Mess from FABRIMAT SARL. We serve customers across France, offering competitive prices and reliable service.

What is the price of the 994310822000001?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Ephy Mess in France?

While we are not the official distributor or seller of Ephy Mess in France, we source our products from reliable channels and offer you original Ephy Mess equipment at competitive prices.

How can I access 994310822000001 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 994310822000001 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 994310822000001?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
