| BRAND | BFI AUTOMATION |
| Product | CFC2000UV1EX |
| Description | Compact Flame Controller |
| Internal code | FBR4295179 |
| Weight | 3.226 |
| Custom code | 84169000 |
| Technical specification | 7013-2002-00 relay and 0/4-20mA output built-in in an ATEX zone 1 housing Dual channel compact system for continuous monitoring of gas and oil burners of any power with additional frequency analysis for a better selectivity. The compact flame controller is equipped with a semiconductor sensor whose spectral sensitivity lies in the UV range. An electronic aperture continuously controls its functioning. Flame intensity as well as the flame relay status is indicated via LEDs. Safety switch off time can be adjusted by jumper and software (1-5 s). Sensitivity, switch ON/OFF level and switch ON delay can be set by software also. An online visualisation of the flame radiation is possible by BFI software. The Compact Flame Controller is built in in a ATEX-zone 1 housing. Further technical details: Two separate and adjustable sensitivity levels Floating change-over contact for the signals Flame ON/OFF Flame relay: potential-free change-over contact max. 48V switching voltage max. 1A switching current max. 30W switching power Flame signal output: 0/4-20mA (Ra <250 Ohm) Spectral range: 190-550nm Operation mode: continuous operation Viewing angle: 2.7° Self checking: once per 800ms Supply voltage 24V DC Current consumption: approx. 200mA Ambient temperature: -20 to +70°C Data transfer via: RS232/Infrared Interface Electrical connection: 3m fixed cable Dimension [mm]: L 285 x D 120 Housing: aluminium, RAL5010, IP66 ATEX-Zone1: II 2G Ex d IIC T6 Gb II 2D Ex tb T80°C Db SIL: SIL3 |
Where can I buy CFC2000UV1EX by BFI AUTOMATION in France?
You can purchase CFC2000UV1EX by BFI AUTOMATION from FABRIMAT SARL. We serve customers across France, offering competitive prices and reliable service.
What is the price of the CFC2000UV1EX?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of BFI AUTOMATION in France?
While we are not the official distributor or seller of BFI AUTOMATION in France, we source our products from reliable channels and offer you original BFI AUTOMATION equipment at competitive prices.
How can I access CFC2000UV1EX catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CFC2000UV1EX on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CFC2000UV1EX?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
