| BRAND | Labom |
| Product | CS2110-A1090-H11-N71-T31-K1085-W4020-W2002 DF3710-HY-F4-A4007-L22 |
| Description | pressure transmitter |
| Internal code | FBR4804468 |
| Weight | 1 |
| Custom code | 90262020 |
| Technical specification | CS2110- PRESSURE TRANSMITTER/PRESSURE SWITCH PASCAL CS for diaphragm seal operation, hygienic, see data sheet D4-017-42 A1- pressure sensor: piezoresistive for gauge pressure 090- measuring range -1...5 bar, overload limit 20 bar measuring accuracy: linearity, hysteresis, repeatability <= 0.2 % of span H11 - output signal: 4...20 mA, 2-wire technology N71 - switching output: 2 floating contacts with common power supply (PNP), switching capacity 30 VDC, 200 mA T31 - electrical connection: circular connector M12x1 (8 pins) K1085- design: standard W4020 - ADDITIONAL DESIGN: marking (adhesive label), see below W2002 CALIBRATION PROTOCOL: with 5 measuring points DF- INLINE DIAPHRAGM SEAL for food / pharmaceuticals / biotechnology see data sheet D5-064 37 - process connection: for ISO 1127-pipes Tri-clamp connection on both sides 10 -nominal width: pipe DN/OD 13.5, pipe inside-ø 10.3 mm Tri-Clamp connection DN 1/2", PN 25, outside-ø 25 mm HY- hygienic design per EHEDG Doc.8 and ASME BPE SF3: surface roughness (wetted parts) - turned parts Ra <= 0.76 µm - diaphragm Ra <= 0.38 µm - weld seam Ra <= 0.76 µm F4 insertion length L: 96 mm A400 connection of meas. instrument directly welded 7 material wetted parts: diaphragm st. steel mat.-no. 1.4435 (316L), basic body st. steel mat.-no. 1.4404 (316L) L22 system filling: Synthetic oil, free of silicon FD1 acc. to FDA 21 CFR 178.3570 / H1-registered operating temperature range -10...+140 °C |
Where can I buy CS2110-A1090-H11-N71-T31-K1085-W4020-W2002 DF3710-HY-F4-A4007-L22 by Labom in France?
You can purchase CS2110-A1090-H11-N71-T31-K1085-W4020-W2002 DF3710-HY-F4-A4007-L22 by Labom from FABRIMAT SARL. We serve customers across France, offering competitive prices and reliable service.
What is the price of the CS2110-A1090-H11-N71-T31-K1085-W4020-W2002 DF3710-HY-F4-A4007-L22?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Labom in France?
While we are not the official distributor or seller of Labom in France, we source our products from reliable channels and offer you original Labom equipment at competitive prices.
How can I access CS2110-A1090-H11-N71-T31-K1085-W4020-W2002 DF3710-HY-F4-A4007-L22 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CS2110-A1090-H11-N71-T31-K1085-W4020-W2002 DF3710-HY-F4-A4007-L22 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CS2110-A1090-H11-N71-T31-K1085-W4020-W2002 DF3710-HY-F4-A4007-L22?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
