Prices K-M5-00-00 Hengesbach France

BRAND	Hengesbach
Product	K-M5-00-00
Description	Conductive conductivity meter
Internal code	FBR4885012
Weight	1.5
Custom code	90278930
Technical specification	A-CONDUTEC Ordering details Process connection: Conical socket with groove nut in accordance with DIN 11851 DN 50 Option: no option --- 1. Transmitter: Polyamide housing, dimensions 100x100x60mm³, with integrated digital display Electrical connection: M20x1.5 cable screw for cable diameter 6- 12mm, protection class IP 65 in accordance with EN 60529 Measurement ranges freely programmable from 0.. 20 μS/cm to max. 0.. 500 mS/cm (see relevant technical data for the LF measuring cell) 1st output 4-20 mA, 2-wire for conductivity, galvanically isolated 2nd output 4-20 mA in 2-wire for temperature, programmable in the range T=- 40.. +160°C 2 contactless alarm outputs Supply voltage 14... 30 VDC 2. 4-electrode conductivity measurement cell Can be used for conductivities in the range of 0... 1 mS/cm to 0... 500 mS/cm. Accuracy approx. 0.02 mS/cm. Cell constant C=0.4 (C=0.5 with process connections G1 and G3) Working temperature TA = -10... +120°C. Steam sterilizable 1 h to TR = 140°C. Pressure resistance 16 max. bar Temperature measurement with integrated Pt1000 in accordance with DIN IEC 751. parts in contact with media made of PEEK, PVDF, graphite and stainless steel (weight 1.4404), EPDM sealing material with FDA.

Hengesbach - K-M5-00-00 referenced Conductive conductivity meter product produced by high technology.
If you need other products from Hengesbach, please send us an inquiry by e-mail. We are one of the few companies which can present an offer for this product. You can find the most competitive prices about endustriel accessories in our company. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy K-M5-00-00 by Hengesbach in France?

You can purchase K-M5-00-00 by Hengesbach from FABRIMAT SARL. We serve customers across France, offering competitive prices and reliable service.

What is the price of the K-M5-00-00?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Hengesbach in France?

While we are not the official distributor or seller of Hengesbach in France, we source our products from reliable channels and offer you original Hengesbach equipment at competitive prices.

How can I access K-M5-00-00 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for K-M5-00-00 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for K-M5-00-00?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
