| BRAND | Badger Meter |
| Product | 141346 |
| Description | Liquid flow meter |
| Internal code | FBR3394033 |
| Weight | 1 |
| Custom code | 9028 20 00 |
| Technical specification | RCDL M25 3/4" PPO Viton ILR 701 with display RCDL M25 with ILR701 electronic counter Material and technical data: Case: nylon Measuring chamber: Noryl (PPO) O-rings: Viton Measuring range: 1-100 l/min Measurement accuracy: +/- 1.5% of the value P-max: 16 bar t-max: 50°C Connection: R 3/4" outside Installation length: 190 mm Installation position: horizontal, standing ILR 701 electronic counter Display 1: programmable flow indicator, Format xxxx.x, in litres/min (QT, PT, GAL) /min OR resettable totalizer Format xxx.xxx decimal place is changed when overflow shifted xxxx.xx; xxxxx.x; xxxxxx Indicator 2: Non-resettable totalizer 11 digits and resettable 5-digit totalizer Linearization: optional 9-point linearization Memory display: EEPROM, data retrieval at battery replacement Units: liters, gallons, pints, quarts (time unit in x/min.) Temperature: 0-80°C Pulse capture: Reed Correction factor: 0.5000-2.0000 Power supply: 3 VDC CR123A Protection class: IP65 |
